Product Details
SPECIAL FEATURES
1.It's adopted hight temperater oil pump, Max working temperature can be 300 degrees, ?widely used in casting, moulding and rubber industry.
2.Adopted PID controller, ?temperature accuracy within ±1 degrees, long constant time and high effect to save power.
3.Automatic inspect failure and alarm. ?and Fault display for easy maintenance.
4.LCD shows the actual and set temperatures-, direct and visual operations and easy to control.
5.With forcing cooling when machine stop, ?Timing switch for safety and save oil.
6.Separation control box design to avoid the water and gas intrusion ?to extend the components service life.
SPECIFICATIONS
MODEL | TML-9-0 | TML-12-0 | TML-18-0 |
HEATINGMEDIUM | high temperature heat-transfer oil | ||
TEMPERATURERANGE | directcooling | ||
COOLING METHOD | 30-180℃ | ||
HEAT WATER | 1/2”*2 | 1/2”*2 | 3/4”*2 |
COOLING WATER PIPEINCH | Ф13 | Ф13 | Ф13 |
MAX PRESSURE(KG/CM2) | 4 | 4 | 3 |
PUMP POWER | 1HP | 1HP | 1HP |
PUMP MAX FLOW PRESSURE(L/min) | 50 | 50 | 135 |
HETER(KW) | 9*1 | 9*1 | 9*1 |
TANK CAPACITY(L) | 40 | 40 | 60 |
ALARM FUNCTION | Defauit Phase/ antiphase/ lack oil/over loading/oreheat | ||
DIMENSIONS(LxWxH) | 1050*380*820 | 1050*380*820 | 1170*520*930 |
NET WEIGHT(kg) | 120 | 125 | 180 |
